- Brand: Gigabyte
- Model: X299X Aorus Master
- Form Factor: E-ATX
- CPU Socket Type: LGA 2066
- CPU Type: Support for Intel® Core™ i7-7800X and above X series processors/Intel® Core™ i9 X series processors in the LGA2066 package
- Chipset: Intel® X299 Express Chipset
- Number of Memory Slots: Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs
- Memory Standard: Support for DDR4 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933/2666/2400/2133 MHz memory modules
- Maximum Memory Supported: Intel® Core™ X series 48-lane processors: 8x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity) of system memory
Intel® Core™ X series 44-lane/28-lane processors: 8x DDR4 DIMM sockets supporting up to 128 GB (16 GB single DIMM capacity) of system memory - Channel Supported: Dual Channel Memory Architecture
- Multi-Gpu: Support for NVIDIA® Quad-GPU SLI™ and 3-Way (with 44-lane CPU) / 2-Way (with 44 & 28-lane CPU) NVIDIA® SLI™ technologies
Support for AMD Quad-GPU CrossFire™ and 3-Way (with 44-lane CPU) / 2-Way AMD CrossFire™ technologies - Storage: 1x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe x4/x2 SSD support) (M2M)
1x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q)
* The M2M and M2Q connectors become unavailable when an Intel® Core™ X series 28-lane processor is used.
Chipset:
1x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2P)
8x SATA 6Gb/s connectors - Raid: The M2M and M2Q connectors must work with an Intel® VROC Upgrade Key to support RAID configuration. If you want to use VROC, refer to Chapter 3-4, "Configuring Intel® Virtual RAID on CPU (Intel® VROC)," for setup instructions.
* Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA connectors. - Usb Ports: Chipset+2 ASMedia® USB 3.2 Gen 2 Controllers:
1x USB Type-C™ port with USB 3.2 Gen 2 support, available through the internal USB header
1x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support
1x USB 3.2 Gen 2 Type-A port (red) on the back panel
Chipset+Realtek® USB 3.2 Gen 1 Hub:
2x USB 3.2 Gen 1 ports on the back panel
2x USB 2.0/1.1 ports on the back panel
Chipset+USB 2.0 Hub:
4x USB 2.0/1.1 ports available through the internal USB headers
Chipset:
8x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
2x USB 2.0/1.1 ports available through the internal USB header - Audio: Realtek® ALC1220-VB codec
ESS SABRE9218 DAC chip
High Definition Audio 2/4/5.1/7.1-channel
Support for S/PDIF Out - Slot: Intel® Core™ X series 48-lane processors:
2x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
2x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
Intel® Core™ X series 44-lane processors:
2x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
1x PCI Express x16 slot, running at x8 (PCIEX8_1)
1x PCI Express x16 slot, running at x4 (PCIEX8_2)
Intel® Core™ X series 28-lane processors:
1x PCI Express x16 slot, running at x16 (PCIEX16_1)
1x PCI Express x16 slot, running at x8 (PCIEX16_2)
1x PCI Express x16 slot, running at x4 (PCIEX8_2) - Lan: 1x Aquantia 5GbE LAN chip (5 Gbit/2.5 Gbit/1000 Mbit/100 Mbit) (LAN1)
1x Intel® GbE LAN chip (10/100/1000 Mbit) (LAN2) - Wireless: IIntel® CNVi interface 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
Bluetooth 5 - Internal Connectors: 1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connectors
1x CPU fan header
1x water cooling CPU fan header
4x system fan headers
2x system fan/water cooling pump headers
2x addressable LED strip headers
2x RGB LED strip headers
3x M.2 Socket 3 connectors
8x SATA 6Gb/s connectors
1x Intel® VROC Upgrade Key header
1x front panel header
1x front panel audio header
1x USB Type-C™ port, with USB 3.2 Gen 2 support
2x USB 3.2 Gen 1 headers
3x USB 2.0/1.1 headers
1x noise detection header
1x Thunderbolt™ add-in card connector
1x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
1x power button
1x reset button
2x temperature sensor headers
1x Clear CMOS jumper
2x BIOS switches - Back Panel Ports: 1x Q-Flash Plus button
1x Clear CMOS button
1x USB Type-C™ port, with USB 3.2 Gen 2 support
1x USB 3.2 Gen 2 Type-A port (red)
6x USB 3.2 Gen 1 ports
2x USB 2.0/1.1 ports
2x RJ-45 ports
2x SMA antenna connectors (2T2R)
1x optical S/PDIF Out connector
5x audio jacks - LED Lighting: Support RGB Lighting Effect in Full Colors with RGB FUSION 2.0 supported with Multi-Zone Addressable LED Light Show Design, support Addressable LED & RGB LED Strips
- Dimensions: 30.5 x 26.9 cm
- Operating System: Support for Windows® 10 64-bit
- Warranty: Chính hãng 3 năm
- Giao hàng: Toàn quốc. Miễn phí phạm vi nội thành TP.HCM (Chính sách giao hàng Nguyễn Đức)
Main Gigabyte X299X Aorus Master
Giá: 11,350,000₫ (Giá bao gồm VAT)
Giá trước đây 11,990,000₫ Tiết kiệm 6%
